The J-I4G is a discreet 4G antenna designed to be mounted inside the vehicle cab – normally to the windscreen, although the antenna can also be mounted to plastic parts of the vehicle interior.
The J-I4G is very easy to fit, and comes supplied with an automotive-grade adhesive pad. The antenna is constructed from weather resistant plastic and is suitable for use in semi-exposed scenarios.
The J-I4G is ultra-wideband, ground plane independent, and covers the full range of 2G, 3G and 4G frequency bands globally. An integrated 3m cable is supplied.
Please note that the J-I4G is not suitable for being mounted to heat reflective glass, or to windscreens which are heated by a fine wire mesh. It can, however, be mounted to tinted or double-glazed glass.
698-960 / 1710-2170 / 2396-2700 MHz
Length: 131 mm
Width: 21.7 mm
Thickness: 7 mm
-40 to +70 °C
Fixing: Acrylic adhesive pad
Cable length: 3m
Cable type: standard (RG174)
Approximate cable loss per metre: 1.4 dB (although varies with frequency)
Connector: SMA Male
In-CarPC Part No: J-I4G / JI4G
Panorama Part No: EF-BC3G-26-3SP
