The J-IWS is a dual-band (2.4 & 5 GHz) Wi-Fi antenna which connects directly to our vehicle PCs or routers. We recommend a direct-connection antenna such as the J-IWS when Wi-Fi communication will be taking place entirely within the vehicle (e.g. between an in-vehicle router and other on-board mobile devices).
An articulated right-angled connector offers great flexibility for optimum antenna positioning, and the antenna has a sleek profile for low visual impact.
The J-IWS normally allows a vehicle PC or router to communicate with external networks or devices that are close to the vehicle, but for longer range communication and better performance an external antenna is recommended.
2396-2485 & 4900-6000 MHz
+ 3 dBi @ 2.45 GHz
+ 5 dBi @ 5.4 GHz
Length: 163 mm
Width: 22 mm
Thickness: 7 mm
-30 to +70 °C
Mounts directly to device’s SMA socket
SMA Male Reverse Polarity (if ordered with a router) or SMA Male (if ordered with a PC).
Variant with SMA Male connector:
- In-CarPC Part No: J-IWSN / JIWSN
- Panorama Part No: PWB-24-58-RSMAP
Variant with SMA Male Reverse Polarity connector:
- In-CarPC Part No: J-IWSR / JIWSR
- Panorama Part No: PWB-24-58-RSMARV
